LOD-662L
详情
Features
This Auto Diagnostic Scanner is used for Reading and Clearing Vehicle Trouble Codes.
It can be user setup to any of eight languages:English, French, Spanish, Japanese, Italian, Russian, Portuguese and Germany. so all the information can be read and understood in your favorite language.
Prime Functions
Read DTCs
Clear DTCs
Read MIL
View freeze frame data
I/M readiness monitor status
Display live data stream
O2 sensor data
On-board monitoring test
Read pending codes
Read permanent codes
Read vehicle information
Multilinguil user interface
Internet upgradable
Specifications
1)Screen:2" TFT, 220*176 LCD display
2)Input voltage range:9-18V
3)Connection: OBD16PIN
4)Operating current:150mA@12V(Typical)
5)Power consumption:1.8W(Typical)
6)Operating temperature:32°F-122°F/0°C -55°C
7)Storage temperature:-4°F-158°F/-20°C -70°C
8)Working humidity:<80%
9)Dimension:125.5*65.5*19mm(L*W*H)
10)Weight:<200g
Package Content
1)Main Unit
2)Quick Start Guide
3)USB Cable
Connections
1)Turn the ignition off.
2)Locate the vehicle's DLC socket.
3)Plug ArtiLink 201 connect the vehicle's DLC.
4)Turn the ignition on. Engine can be running or off.
5)After finishing, the system will start initializing. After initialization, the system will enter the main menu interface.
Update
Free update for lifetime on www.topdon.us
Easy update: connect this tool with PC, download the file and move it to scan tool’s disk, then the update is complete.
Warranty:
12-month warranty for any quality problems
First 3-month warranty for free refund or replacement
This Auto Diagnostic Scanner is used for Reading and Clearing Vehicle Trouble Codes.
It can be user setup to any of eight languages:English, French, Spanish, Japanese, Italian, Russian, Portuguese and Germany. so all the information can be read and understood in your favorite language.
Prime Functions
Read DTCs
Clear DTCs
Read MIL
View freeze frame data
I/M readiness monitor status
Display live data stream
O2 sensor data
On-board monitoring test
Read pending codes
Read permanent codes
Read vehicle information
Multilinguil user interface
Internet upgradable
Specifications
1)Screen:2" TFT, 220*176 LCD display
2)Input voltage range:9-18V
3)Connection: OBD16PIN
4)Operating current:150mA@12V(Typical)
5)Power consumption:1.8W(Typical)
6)Operating temperature:32°F-122°F/0°C -55°C
7)Storage temperature:-4°F-158°F/-20°C -70°C
8)Working humidity:<80%
9)Dimension:125.5*65.5*19mm(L*W*H)
10)Weight:<200g
Package Content
1)Main Unit
2)Quick Start Guide
3)USB Cable
Connections
1)Turn the ignition off.
2)Locate the vehicle's DLC socket.
3)Plug ArtiLink 201 connect the vehicle's DLC.
4)Turn the ignition on. Engine can be running or off.
5)After finishing, the system will start initializing. After initialization, the system will enter the main menu interface.
Update
Free update for lifetime on www.topdon.us
Easy update: connect this tool with PC, download the file and move it to scan tool’s disk, then the update is complete.
Warranty:
12-month warranty for any quality problems
First 3-month warranty for free refund or replacement
